• Contact Resistance：50mΩ Max.Initial
• Insulation Resistance：10GΩ Min.@1000VDC
• Dielectric Strength：500VAC for 1 minute
• Operation Temperation：-40℃ to 95℃
• Storage Temperature：-40℃ to 95℃
• Electrical Rating：30mA@28VDC
• Electrical Life：20,000 cycles
• Full Travel：2.0mm
• Contact Arrangement：SPST,SPDT
• Actuation Force：ST:490 grams
• DT 1st Position：600 grams
• DT 2nd position：1150 grams
|
 |
 |
| Part Number | Contact Resistance | Insulation Resistance | Dielectric Strength | Operation Temp. | Storage Temp. | Electrical Life | Full Travel | Contact Arrangement | PDF下载 |
|---|---|---|---|---|---|---|---|---|---|
| R2991-1 | 50mΩ Max.Initial | 10GΩ Min.@1000VDC | 500VAC for 1 minute | -40℃ to 95℃ | -40℃ to 95℃ | 20,000 cycles | 2.0mm | SPST,SPDT | 暂无 |
| R2991-2 | 50mΩ Max.Initial | 10GΩ Min.@1000VDC | 500VAC for 1 minute | -40℃ to 95℃ | -40℃ to 95℃ | 20,000 cycles | 2.0mm | SPST,SPDT | 暂无 |
