• Rating : 150mA, DC 42V (Switching)
200mA, DC 42V (None Switching)
• Contact Resistance : 80mΩ Max.
• Insulation Resistance :100MΩ Min at DC 250V
• Operating Force : 700gf Max.
• Life Cycle : 10, 000 steps
• ealing : IP67 (Dust & Water proof)
*Except cross type of Actuator("Е"Туре)
|
|
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Operating Force | Life Cycle | Sealing | PDF下载 |
|---|---|---|---|---|---|---|---|
| RA | 50mA, DC 42V (Switching);200mA, DC 42V (None Switching) | 80mΩ Max | 100MΩ Min at DC 250V | 700gf Max. | 10,000 steps | IP67(Dust&Water proof) | 暂无 |
