• Rating: 100mA, DC 5V (Switching)
100mA, DC 50V (None Switching)
• Contact Resistance: 100mΩ Max.
• Insulation Resistance: 100MΩ Min. at DC 100V
• Operating Force: 200gf Max.
• Life Cycle: 10,000 steps
• Sealing: IP67 (Dust & warter proof)
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Operating Force | Life Cycle | Sealing | PDF下载 |
|---|---|---|---|---|---|---|---|
| RC | 100mA,DC 5V(Switching);100mA,DC 50V(None-Switching) | 100mΩ Max | 100MΩ Min at DC 100V | 200gf Max. | 10,000 steps | IP67(Dust&Water proof) | 暂无 |
